PRUFTECHNIK INDONESIA: August 2018

OPTALIGN SMART RS5 - PRUFTECHNIK INDONESIA

The power of precision shaft alignment. With OPTALIGN smart RS5, shaft alignment has never been so smooth. With the continuous SWEEP measurement mode, hundreds of positions are automatically measured as shafts are rotated. Measurement can start in any direction with the sensors at any position. All relevant alignment results, including soft foot, are graphically displayed on one screen.

Smiley symbols clearly indicate the alignment status so that there is no need to interpret the results. Some Specific Symbol on machine indicates the alignment status. So, no doubt, we are getting correct results.

Features:

1. This is a fine alignment device of horizontal, vertical mounted machines and also used in coupled and uncoupled shaft.
2. Sensor with XL HD detectors and MEMS inclinometer
3. Hundreds of positions are automatically measured during shaft rotation - SWEEP.
4. Live monitoring of horizontal and vertical corrections at any angular sensor position on the shaft - Concurrent Live Move
5. Flip machines functionality
6. Save measurement reports as PDF onto a USB stick
7. Bluetooth communication integrated in handheld unit and RS5 sensor
8. Straightness results on both axes with only one measurement (Option)
9. Ensure smoother operation with integral Bluetooth and XXL detector area.

Application

1. Shaft alignment of critical rotary machine with easiest way.
2. Measuring Straightness

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

CENTRALIGN ULTRA - PRUFTECHNIK INDONESIA

Precise, fast and intuitive bore alignment. CENTRALIGN Ultra is a precision laser bore alignment system which is fast, very precise, and provides a clear measurement protocol, unlike traditional methods. CENTRALIGN Ultra can be used for Turbines, Compressors, Engines, Gear Boxes, Stern Tubes, etc. You may also visit : Rotalign Ultra iS

This is also a laser alignment system but this is design for the measurement and alignment of the internal components of rotating machines bearing rings, nozzles, and inner shells and turbines castings with upper halves installed or off. This is most advanced device using method as for the same purpose we used to traditional method by using wires, micrometers and cumbersome, theodolite telescopes.

Basically, CENTRALIGN Ultra used for Bore alignment in combustion engines, compressors, pumps, gearboxes, stern tubes and in steam and gas turbines. Below are the features:

1. True bore center measurement: Determination of the eccentricity error
2. Ability to measure more than 3 points over the bore guarantees highest accuracy
3. Patented universal pointer brackets with rotating sensor holder improve measurement precision and handling
4. Measurement of both magnetic and non-magnetic bores with diameters ranging from 45 mm to over 4000 mm
5. Laser range distances up to 50 m (164,042 ft) with the Long Range Laser
6. Control sensor (option) for automated compensation of potential laser drift
7. Enter the reference line position, the rotor sag and the thermal growths

Application
Bore alignment for Turbines, Compressors, Engines, Gear Boxes, Stern Tubes, etc.

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

ROTALIGN ULTRA iS - PRUFTECHNIK INDONESIA

The intelligent alignment platform. No matter whether it is a motor-pump set or turbomachinery trains, ROTALIGN Ultra iS is a highly versatile system made to handle alignment on all types of rotating machines. This best-of-breed laser alignment system will save you a lot of time and effort! The modular system is easily configured with expert modules such as Vibration Acceptance Check, Live Trend for the monitoring of thermal growth, simultaneous multi-coupling measurement, RFID machine identification, and geometric measurements.

Laser alignment with intelligence for maximum user comfort

It is well known that ROTALIGN Ultra iS is the only high end intelligent machine for alignment platform for the markets which have requirements like alignment and balancing. This is perfect equipment to resolve all issues related to alignment and balancing in rotating machine.

    This Powerful Instrument for 100% stress-free shaft alignment of all kinds of coupling and shafts.
    This Tool is also useful in Live Monitoring of machine displacements and has expert modules like Vibration acceptance to check noise & vibration.
    Measurement platform for geometric applications.

In addition, ROTALIGN ultra iS is compatible with the ALIGNMENT CENTER software for professional reporting and managing your alignment jobs.

Application
1. A super intelligent laser alignment system in the world with 7 axis measurement.
2. Eliminates human error with Intellisweep measurement.
3. Also, provides high end functionality for live thermal growth measurement.
4. Measurement platform for geometric applications
5. Vibration Acceptance Check
6. Live Trend for the monitoring of thermal growth
7. Simultaneous multi-coupling measurement
8. RFID machine identification

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

WEARSCANNER - PRUFTECHNIK INDONESIA

WEARSCANNER detects electrically conductive particles in oil using a patented method based on the eddy current principle. Results are independent of oil temperature, flow rate, viscosity, air and water contents or oil color (darkening). The particles are counted real-time and classified according to their size. Minimum particle detection size is down to 50µm to ensure the detection of the slightest start of detrimental and abnormal wear.

Online Particle Counter Monitors Wear Debris in Oil

This is an Online Particle Size Distribution Counter Monitors Wear Debris in Oil that helps in following ways:

    Avoids consequential damage
    Enhances the availability of the plant
    Switching output for alarms
    Recognizes bearing & gear teeth damage

Recognize damage before they totally fail to operate. Use’ Wear Scanner’.

See how WEARSCANNER® works:

    Each peak represents a particle that flows through the sensor tube.
    The amplitude indicates the size of the particle.
    The peaks are counted in set time intervals
        And the number of peaks per time interval is transmitted via Modbus TCP.
    The size categories – three in this case – are configured for each particular situation.
    The time resolution and scan rate can be selected.

The sensitivity of the WEARSCANNER® can be adapted by adjusting the gain, power and filter to the machine application.

General rule: As you know, if large will be the particle that occurs more damage.

Technical details:

Fitting dimensions

1/2“- other sizes available upon request

Measuring method

Eddy current, differential coil principle

Particles

Ferritic or non-ferritic

Particle size class

Up to 8 size classes can be set

Flow velocity

0.01m/s – 5m/s (0.1 - 40 l/min)

Oil type

Mineral, synthetic or biodegradable

Oil pressure

Max. 16bar

Temperature range

-20°C – 80°C

Signal processing

Particle distribution counters with integral. Average determination and classification.

Application
Online wear particle monitoring system.

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

LEVALIGN EXPERT - PRUFTECHNIK INDONESIA

Flatness and level with a spin. LEVALIGN expert uses a horizontally and vertically self-leveling spinning laser with a 100-meter measurement range in conjunction with a 70-mm range sensor. It ensures easy one-man operation for wide-ranging flatness and level measurement tasks. LEVALIGN expert is the ideal package for OEMs and companies who offer full maintenance services to improve machine running condition and productivity.

To check Flatness and level and that made easy with self-levelling and spinning laser. Wireless communication between sensor and ROTALIGN Ultra computer transfers measurement data for analysis and evaluation of surface profile. ROTALIGN Ultra and Sensors connected with wireless and computer transfers measurement data for analysis and evolution of surface profile. We have geometrical alignment products and geometrical measurement systems.

LEVALIGN Expert basically uses a horizontally and vertically self-spinning laser with 100 meter measurement range in conjunctions with 70-mm range sensors. It ensures easy one-man operation for wide-ranging flatness and level measurement tasks.

    PC software for measurement analysis and professional reporting
    Powerful software functionalities to compare two surfaces, e.g. in a press, and to extend the measurement range for large surfaces
    Integrated wireless communication
    Measure flatness, straightness, parallelism, perpendicularity and level of flanges and foundations
    Efficient and easy one-man operation with self-leveling and rotating laser
    Laser range dia. 200 m, sensor measurement range 70 mm

Application
1. High resolution flatness measurement for large area with easiest measurement methods
2. Provides clear view of level differences for rectangular and circular surfaces.

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

VIBROTECTOR - PRUFTECHNIK INDONESIA

Knowing exactly when to shut a machine off can save time and money by preventing unexpected repairs. VIBROTECTOR is the ideal vibration monitoring transmitter for all machines running under approximately constant operating conditions such as: fans, ventilators, pumps or electric motors.

This Vibration transmitter for effective machine protection and robust machine vibration transmitter which is available in two versions which differ in frequency range.

VIBROTECTOR® is the ideal vibration monitor for all machines which run under approximately constant operating conditions such as, e.g.

    Fans
    Ventilators
    Pumps
    Electric motors

VIBROTECTOR® records broadband machine vibrations and transfers the resulting overall value as a current signal (4-20 mA) to the connected process control system. This value is compared with specified alarm thresholds and an alarm issued to the operating personnel if a value is exceeded.

See why VIBROTECTOR is useful for monitoring machine vibrations:

    Low installation costs
    Continuous vibration monitoring
    Direct alarm notification in the control system
    Simple to mount on the machine
    Conforms to ISO 10816-3 & 10816-7
    Ideal for OEMs
    No additional hardware required
    No additional supply voltage required
    Robust compact design
    4-20mA output

This can be used in industrial areas and hazardous areas with different type’s connection cables like with straight plug and with angled plug.

Application
1. Cost efficient Vibration monitoring of the Plant control system.
2. Vibration analysis on Fan, Ventilators, Pumps and Electric motors

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

IN-SITU BALANCING - PRUFTECHNIK INDONESIA

More often, unbalance, is requried to be corrected at site. Our specialised in-situ balancing service helps carry out accurate balancing of rotors in the plant without removing them. Accurate results are achieved within required tolerance within short period of time.

In-suit balancing is the procedure that makes correction in unbalanced rotating machine. Because with misalignment, unbalanced causes more premature and catastrophic failures in rotating machinery than any other fault.

Benefits of In-suit Balancing

    Reduces downtime, labour and material costs
    Can be planned into scheduled short time outages e.g. machine mould or process changes
    Extends bearing and machine life
    Reduces the possibility of catastrophic failures
    Increases safety

Due to Misalignment and unbalanced machine and its shaft, Un-even mass distribution over the whole machine then it produces high vibration during rotation which affects machine construction. This can cause bearing, seals and coupling may become fail.

Some equipment from PRUFTECHNIK is able to detecting and eliminating unbalanced in just few steps. For all types of rotating fans of all Sizes and Shapes are treated by different types of balancing devices, such devices are also ideal for special requirements, such as field balancing of rotor blades on wind turbines.

Application
1. In situ dynamic balancing for rotors
2. These Services can be helpful for Rotating Machine
    Fans
    Ventilators
    Belt Pulleys and Couplings

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

BORE ALIGNMENT - PRUFTECHNIK INDONESIA

Laser based bore alignment techniques has great advantages over traditional methods, like, piono wire techniques and dummy shaft. Precise, accurate and relaible results achived for multiple bore within short measurement time. Correction can also be monitored with live move.

Application
Bore alignment for Turbines, Compressors, Engines, Gear Boxes, Stern Tubes, etc.

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

PARALIGN - PRUFTECHNIK INDONESIA

The revolutionary method for roll alignment. Production systems in the paper, converting and steel industries require increasingly higher speeds and larger working widths. The parallel alignment of rollers is therefore more important than ever. Even small installation deviations during replacement of a roller or changes in the foundation affect the parallelism of rollers. This often results in web runs or breaks. Roller parallelism is a must – and with PARALIGN now easier than ever!

A perfect method for roll alignment

Roll alignment is a fast and efficient & highly accurate, even without line of sight. Roll alignment by the innovators of inertial alignment. PARALIGN is a unique alignment system that contains three high-precision laser gyroscopes as used in the navigation of wide-bodies jest and submarines.

The measurement results are significantly more precise, absolutely repeatable, and measuring takes a fraction of the time required by conventional procedures.

    Reduces machine downtime to a minimum with extremely quick set-up and service time
    Highly accurate system for all measured rolls, even when rolls are far apart, even without line of sight
    Can be used in enclosed (housed) machinery
    Can be used in inhomogeneous temperature profiles
    Automatic reporting of the "as is" situation both graphically and numerically
    On-site instant results and evaluation.

Application
Roll alignment measurerment with high tech measurement technology ensuring precise measurement for large number of rolls.

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

SHAFTALIGN - PRUFTECHNIK INDONESIA

The efficiency of laser shaft alignment. SHAFTALIGN ideally combines intuitive operation and accuracy for precision laser shaft alignment of rotating machinery. The system's intuitive Autoflow capability guides the user step by step to measure the machinery alignment condition. All relevant alignment results are graphically displayed on one screen.

Need Shaft Alignment Fast and Efficient with SHAFTALIGN - Since many years, PRÜFTECHNIK has continued to develop excellent equipment for quality check of all types of rotating machine. Shaftalign is one of the best equipment for precision shaft alignment systems; our machine is mostly used in Power, chemical, water treatment, production and processing industry.

Why alignment?

Rotating machinery is susceptible to misalignment. Machines that are well aligned at the commissioning stage and thereafter regularly maintained will in the long term reduce both plant operating and maintenance costs.

Precision alignment guarantees

1.      Reduced energy consumption

2.      Reduction in bearing, seal, shaft and coupling failure

3.      Reduced bearing and coupling temperatures

4.      Reduced vibration

5.      No breaking (or cracking) of shafts

6.      Secure foundation bolts

Features:

-          Alignment of horizontal, vertical and flange-mounted machines

-          Alignment of coupled, uncoupled and nonrotatable shafts

-          Soft foot check – measure, correct and save results

-          UniBeam for quick adjustment of the single laser beam

-          Active clock measurement mode

-          Automatic evaluation of alignment condition with TolChek®

-          InfiniRange® extends detector measurement range to handle gross misalignment

-          QuickCheck – uses a single dimension to display both horizontal and vertical coupling values

-          Static measurement mode – requires any 3 of the 8 available

-          45° measurement positions

-          Live monitoring of horizontal and vertical machine corrections

-          Save measurement reports as PDF to a USB memory stick

-          Data protection – auto save and resume capability

-          High resolution backlit colour TFT screen

-          Save up to 200 measurement files in the device

Powerful SHAFTALIGN® features:

-          Sweep measurement mode (optional)

-          Active clock measurement mode

-          Automatic evaluation of alignment

-          Live Move

Application
Accurate Shaft alignment of rotary machines

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

ROTALIGN TOUCH - PRUFTECHNIK INDONESIA

Cloud-enabled laser shaft alignment system. ROTALIGN touch is the first cloud-enabled touchscreen laser shaft alignment system with integrated mobile connectivity. Besides offering the best usability in the market, ROTALIGN touch is also the first laser alignment tool fully designed to meet the requirements of the smart factory.

An advanced ROTALIGN machine has many enhanced features like multi-coupling measurement (including multi-coupling live move) and multi-coupling live trends. As per user specific requirements up to six coupling shafts can be simultaneously aligned in real time, due to this it can reduced alignment time up-to 50%.

Powered by the unique sensALIGN and intelliSWEEP measurement technology, ROTALIGN touch features the simultaneously live Move mode.Be ready to change the way you align. 3D display animations, capacitive touchscreen and wizard guidance make the alignment experience as easy as using a tablet or smartphone.

Precision Meets Connectivity

    Vibration Spot Check to measure overall values
    ALIGNMENT RELIABILITY SOFTWARE 4.0 software with cloud data transfer
    Tablet-like capacitive touchscreen with 3D display
    Real time high measurement quality with intelliSWEEP, intelliPASS and intelliPOINT
    Cardan shaft alignment with shaft in place
    Horizontal and Vertical Move simulator
    Extremely durable with strengthened glass screen and tough housing
    Inbuilt mobile connectivity: RFID, Wi-Fi, Bluetooth and camera
    Multi-coupling Shaft measurement up to 6 coupling simultaneously
    Multi-coupling Live-Move in both Horizontal and Vertical directions simultaneously
    Vertical machine alignment with vertiSWEEP continuous measurement mode
    Soft foot diagnosis
    Monitor relative machine positional changes continuously with Multi-coupling Live Trend

Get Voice Apps that works the voice control of ROTALIGN touch

Through this Voice App you can operate ROTALIGN touch laser-shaft and machine-alignment system with voice control connected via Bluetooth of any Pc and mobile. You can operate few functions through voice control without touching the device. Get the App on Google Play

What’s new in ROTALIGN touch

    Manual Soft-foot entry
    Dial gauge input
    Convert measurement to dial gauge
    Single plane coupling
    No Coupling
    Additional machine graphics
    Multi-coupling Measure
    Multi-coupling Move
    Multi-coupling Live Trend
    Manual measurement

Application
1. You can use whenever you need Multi-Coupling measurements
2. Laser shaft alignment on-the-go with cloud connectivity for easiest data transfer

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

PULLALIGN - PRUFTECHNIK INDONESIA

Accurate pulley alignment with laser. PULLALIGN is tailor-made for the job as it is easy to use and only requires a single operator. Due to its versatile design and strong magnets, the units mount onto virtually any pulley face or ring gear. A laser line is projected onto the reflector mounted on the opposite pulley. Parallel offset, vertical and horizontal angle corrections are visually determined by the position of the laser line on both the laser and reflector housing. These alignment parameters are monitored simultaneously.

PRÜFTECHNIK Alignment Systems is the market leader in precision alignment. A large percentage of our hi-tech instruments developed and produced in Germany –are used in top industrial organizations worldwide.
Easy pulley alignment with laser

PULLALIGN® benefits
1. Efficient one-man operation
2. Reduces down time and energy costs
3. Shows offset, vertical and horizontal angle simultaneously
4. Reflected beam technology doubles the distance, enhancing accuracy
5. Only one laser for complete alignment
6. Reduces vibration and belt noise
7. Prolongs belt, pulley and bearing life
8. Time saving method as no cross-checking required
9. Easier to use than conventional methods
10. Supplied in a case or pouch
11. No training required

Application
1. Reduces pulley and belt wear
2. Laser based belt alignment system for pulley.
3. Checking vibration of machinery
4. Checking alignment of Steam turbines and gas turbines
5. Checking alignment of generators Pulley, motors and pumps shaft
6. Checking blowers vibration , turbochargers and alignment of drive trains in cars
7. To Check alignment of Rotating electrical machines with Laser Technology

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

VIBGUARD - PRUFTECHNIK INDONESIA

Advanced Online Condition Monitoring for multiple channels. Online systems work fully autonomously around the clock. Changes in the machine conditions are detected automatically in real time.

Under the Online Condition Monitoring systems, we introduce advance online condition monitoring - VIBGUARD protects your assets with high-end technology.

Pruftechnik VIBGUARD offers synchronous and parallel data acquisition on 20 analog channels. It keeps your equipment safe whenever your complex machine/device sudden shutdown. When then it ensures maximum productivity.

VIBGUARD is ready for FTT spectra, overall values, time signal, shock pulse and more on 20 parallel channels for almost all kind of signal inputs. Vibration, Tacho Pulse, temperature and any other relevant solution inputs like some parameters on rotating machines that is Torque are processed that can be correlate to actual manufacturing process.

VIBGUARD is also available as a portable version for effective high-end troubleshooting.

VIBGUARD Portable - PRUFTECHNIK

Advanced Condition Monitoring on the move

Mobile troubleshooting for specialists

    Portable machine diagnosis system
    Lightweight and quick to install
    IP 64 rated sturdy aluminum case
    20 synchronous measurement channels
    Continuous data recording
    Various configurations available
    Optional industrial PC integrated

Application
Continous online monitoring system for multiple vibration channels and other process parameters.

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

LASER SHAFT ALIGNMENT - PRUFTECHNIK INDONESIA

Accurate shaft alignment is a necessasity for plant machines. Laser Shaft alignment ensure precise and accurate alignment within very short time. Machines runs longer thorugh it's life after this accurate laser shaft alignment services. It also helps user save power consumption for the rotary machines.

Generally, Shaft alignment basically called coupled alignment because this is a process to make two or more rotating shaft co-linear or same in straight line, both vertically and horizontally. But in advance laser technology, we launched laser shaft alignment system that has following advantages:

    Gravity impact will be Zero on laser beams
    Precision laser alignment saves costs, Lowering energy and operating costs
    It can be measure more complex alignment function such as universal joint parallel alignment or cardan shaft
    Exactly measure and compensate for dynamic changes in machinery position, such as those caused by thermal growth of machines.
    Measure vertically as well as horizontally oriented machines.
    It measure vertically and horizontally oriented machines
    During the same measurement process, it can coupled two machine

Precision shaft alignment systems by the makers of OPTALIGN and ROTALIGN

Also, Laser alignment systems for machine geometry and have wide range of shims for all kinds of machine alignment situations. Manage measurement files, view and analyze results, create professional reports.

Our Products comes under laser alignment:

1. Geometrical Laser Alignment Systems

    LEVALIGN expert - Flatness and level with a spin
    LEVALIGN Ultra iS - Flatness, perpendicularity, level, easily done!
    PENTALIGN - Perpendicularity and parallelism of axes and planes
    PARALIGN - The revolutionary method for roll alignment
    CENTRALIGN Ultra RS5 - Alignment of bores, bearings and diaphragms

2. Shaft Alignment Systems

    ROTALIGN touch - Cloud-enabled laser shaft alignment system
    OPTALIGN smart RS5 - The power of precision shaft alignment
    ROTALIGN Ultra iS - The intelligent alignment platform
    SHAFTALIGN OS3 - The efficiency of laser shaft alignment
    ROTALIGN smart RS5 EX - The ultimate intrinsically safe alignment system

Application

1. Precision shaft alignment within less time.
2. Secure fixation of measurement components on various types of shafts
3. Real-time monitoring of dynamic machine positional changes
4. Laser shaft alignment on tablets and smartphones

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

VIBSCANNER 2 - PRUFTECHNIK INDONESIA

VIBSCANNER 2 is the new PRÜFTECHNIK data collector for preventive machine condition monitoring. The handy device convinces with a simple intuitive operation and very short measuring times.

High-speed data collector with triaxial sensor sets new standards

    FAST – Measurement up to 4 times faster than industry standard
    EASY – Intuitive operation thanks to the graphical user interface
    ALL IN ONE – Comprehensive data collection at one push of a button

    VIBSCANNER 2 is a metrological evolution.
    Omni-functional solution for complete offline condition monitoring of rotating equipment.
    High-speed data collector with triaxle sensor sets new standards.

Application
Vibration Data collection, Data acquisition with guided routine measurement tasks

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

VIBXPERT II - PRUFTECHNIK INDONESIA

The Expert in data collection, vibration analysis and field balancing. VIBXPERT II offers all these powerful analysis tools in one user friendly system. VIBXPERT II has a modular structure that allows you to upgrade the device at any time from a basic package for fast route-based data collection to a full-blown 2 channel analyzer with advanced analysis functionalities.

Get Clean and Clear Sound, vibration in Rotating machine because of powerful vibration analyzer. Many more equipment is unbalance, misalignment and defective gear and bearing damage. This is useful for resonance test, bump testing, ODS, model analysis and many more analysis.

Important Facts:

    High-end analysis measurements capabilities
    Field balancing options
    Route data collection functionalities

This is All-in-One Vibration Analyzer and data collector based on new innovated technologies.

Features:

    Powerful analysis and diagnostic tools for machine trouble shooting
    Long-lived battery
    Automatic switchbox support
    Fastest measurements using trending spectra
    User-friendly and intuitive operation

Application
1. A Smart Vibration Analyser with advanced capabilites. Additional capabilites for in-situ dynamic balancing of rotors.
2. Used to perform acceptance measurements of newly produced or installed rotating equipment such as fans, pumps, electric motors or generators.

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

VIBSCANNER - PRUFTECHNIK INDONESIA

The clever data collector & vibration analyzer. With its intuitive one-hand joystick operation and its modular structure, VIBSCANNER is our handheld all-rounder. Thanks to its rugged, waterproof and dustproof housing and design, the instrument works even in the harshest environment.

Sensors & Interfaces

Measure important parameters directly. Use built-in transducers or external sensors attached to rugged connectors.

ISO Alarm Display

Four LEDs for 'everything's OK' (blue), 'pre-warning' (green), 'warning' (yellow) and 'alarm' (red).

Graphic Display

Backlit screen with large intuitive symbols and text in different Languages.

Joystick Navigation

Easy to use, simple to learn! One joystick and two function keys are all the operating controls you need - whether you are right or left-handed.

Power to Last

A practical quick-change rechargeable battery in the handle guarantees 8 hours of operation.

Important Facts

3 built-in sensors: - VIBSSCANNER can measure important machine parameters on rotating machines like Vibration, bearing condition i.e. shock pulse, temperature and RPM

Modular design: - VIBSCANNER can be upgraded to a vibration analyzer by simply adding the “signal analysis” firmware module that allows you to perform orbit & phase analysis, time waveform analysis and long-term time waveform recording.

Versatile vibration analysis tools: - VIBSCANNER can detect machine problems such as unbalance or misalignment and can perform the necessary corrective actions with the optionally available firmware modules for field balancing.

VIBSCANNER can able to find every fine problem such as unbalance or misalignment and can perform the necessary corrective actions with the optionally available firmware module for field balancing

Application
1. Advanced Signal Analysis
2. Balancing in 1 or 2 Planes
3. Smart Data Collector
4. Basic Vibration Analyzers
5. Machine diagnosis
6. Vibration Bearing condition Temperature RPM Process parameters FFT spectrum Signal analysis Balancing

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

VIBREX - PRUFTECHNIK INDONESIA

VIBREX - - PRUFTECHNIK INDONESIA

Adding cost-effective protection to your assets, VIBREX keeps your mind at ease. VIBREX needs no software to monitor machine vibration and bearing condition. The modular system architecture is applicable to all types of machines like pumps, motors, fans, stirrers, refiners and so many more.

Application
Simple and efficient machine survellience system.

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

TELEDIAGNOSE SERVICES - PRUFTECHNIK INDONESIA

Production-critical machines in locations that are difficult to access are ideally monitored around the clock by means of a stationary condition monitoring system. Current measurement data, trends and specific diagnostic measurements can be retrieved and analyzed from any location around the world via secure remote data access.

Application
Supportive solution for online measurement for critical machines

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

VIBRATION ANALYSIS - PRUFTECHNIK INDONESIA

It is the need of an hour for maintenance industry to get an insight of machine health condition. Vibration analysis helps user determine exact condition of machine and act according to it's condition. Machine problems like, unbalance, misalignment, looseness, bearing problems, structural issues can easily be identified with use of appropriate techniques by our experienced analysts.

Application
Vibration measurement and analysis of rotary machines.

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

SONOCHEK - PRUFTECHNIK INDONESIA


SONOCHEK - PRUFTECHNIK INDONESIA

The SONOCHEK handheld testing device comes with two apps: SONOLEVEL and SONOLEAK.

SONOLEVEL

The SONOLEVEL app is the universal leak detection tool. You can search and find leaks with this app, carry out basic condition monitoring tasks for bearings, check that the condensate separator is in working order and monitor electric control cabinets for spark production. To this end, the handheld equipment is fitted with various sensor attachments for both the airborne (non-contact) and the structure-borne (contact-conditioned) transfer of ultrasound.

SONOLEAK

The SONOLEAK app makes the new leak detection system unique. On the one hand, it is used for precise localization of leaks on all compressed air and gas pipes while it can also be used to determine the exact leakage loss volume. A target measurement of only one second is already sufficient to determine the exact loss volume. The corrective action can be identified immediately thanks to the classification of the leak into five different categories.

Application
SONOLEVEL: Pipe leak detection, electrical inspection, steam trap inspection, machine condition monitoring.
SONOLEAK: Automatic leak analysis and evaluation of the amount of loss caused by the leakage according to five different rating levels.

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com

PRUFTECHNIK INDONESIA

The Prüftechnik focuses on helping our customers in the field of Maintenance by offering a wide range of Predictive and Pro-active Maintenance instruments and services to help with our customer's maintenance strategies

PRUFTECHNIK INDONESIA

* Machine Condition Monitoring and Data Collectors (On-line and Off-line)
* Machine Diagnosis, Signal Analysis, Trending and Rotor Balancing Tools
* Optical Laser Shaft Alignment, Pulley/Belt Alignment and Level Alignment Systems
* Bearing Induction Heaters
* Eddy Current Inspection and NDT Tools
* Ultrasonic Leak Detector and Inspection Tools
* Infrared Thermography Instruments
* Oil Test, Motor-check, Torque Analyzer, Boroscope and Electrical Test Instruments
* Services (contract or on-call) and Training courses on Predictive and Pro-active Maintenance

https://www.pruftechnik.com
http://pruftechnik-id.blogspot.com
